Teknion BM_R - Installation Step #9: Component Mounting; Installation Step #10: Component Mounting

B03-50103
E07-0077
#10 x 7/8"
40BH_
E03-50909
Knob 1/4-20
Bouton 1/4-20
#10
#9
E01-50818
1/4-20 x 7/8"
E07-0077
#10 x 7/8"
E07-0077
#10 x 7/8"
BW_
E01-50818
1/4-20 x 7/8"
Expansion Casegoods Installation Guide / Guide d'installation
2021-01-19 14:27
BM_R, BH_WB, BH_CB, BH_PT, BH_MT, BH_EP, BH_LB, BH_L, BH_LT, BH_RB, BH_PP & BHK__ -
Height-Adjustable Table & Kneespace - Mid-Height / Table ajustable en hauteur & Module - Mi-Hauteur
8 / 9
L04-64040_R01
2046
For additional information on this installation contact Technical Support. Pour plus d'informations sur cette installation contactez le support technique.
E07-0077
#10 x 7/8"
