Teknion BM_R - Installation Step #11: Support Bracket Installation; Installation Step #12: Panel Placement

402100
#8 x 5/8"
Expansion Casegoods Installation Guide / Guide d'installation
2021-01-19 14:27
BM_R, BH_WB, BH_CB, BH_PT, BH_MT, BH_EP, BH_LB, BH_L, BH_LT, BH_RB, BH_PP & BHK__ -
Height-Adjustable Table & Kneespace - Mid-Height / Table ajustable en hauteur & Module - Mi-Hauteur
9 / 9
L04-64040_R01
2046
For additional information on this installation contact Technical Support. Pour plus d'informations sur cette installation contactez le support technique.
#11
#12
402101
#8 x 1.5"
X80-64022
or/ou
X80-64024
D02-50502
X80-64023
#8 x 7/8"
E04-50084
402101
#8 x 1.5"
or/ou
Place the panel back.
Remettre le panneau.
X80-64137
B02-64003
