Teknion zones - Configuration Orientation Sheet; ZNFGA Configuration; ZNFGB Configuration; ZNFGC Configuration

Section:
Description:
Page No:
Date:
ORIENTATION SHEET (LEFT OR S CONFIGURATION SHOWN)
May 2019
3 of 9
ZNS_101b
FREESTANDING LOUNGE & SEMI-SUPPORTED SCREENS INSTALLATION
FREESTANDING SCREENS
zones Installation Guides
Zones Orientation Sheet shown as a reference.
ZNFGA
ZNFGA
ZNFGB
ZNFGB
ZNFGC
9 sq. ft.
16 sq. ft.
9 sq. ft.
Greater than 9 sq. ft.
All sizes
ZNFWS
Less than 64 sq.ft
