Tekno EB410.2 - P18_EB410_2 instructions_BagL

TKR1240
Note: Slot in spring
perch should face
outside of car.
TKR1211
TKR6712
TKR6709
TKR6711
TKR6709
TKR6708
TKR6708
TKR1245
TKR6701
TKR6548
TKR1604
TKR6701
TKR6712
*TKR6712A
(Option)
TKR6719A
Step
L-1
Step
L-2
Step
L-3
Step
L-4
Step
L-5
TKR1240
M3x18mm Shock Mnt Screw
x2
TKR1248
M2x4mm Emulsion Screw
x2
TKR1245
M2x5mm Piston Screw
x2
TKR1211
M3 Lock Nut Flange Black
x2
TKR1604
M3x8mm Set Screw
x2
#600 cst
shock oil
Note: Screw rod end on
until distance measures
29mm at full extension.
#600
29.00mm
TKR6712
Note: Black screw
is RH threaded.
It goes on the left
side of the car.
Silver screw is
LH threaded.
It goes on the right
side of the car.
TKR6704
*TKR6704T
(Option)
Thread
Lock
Note: Use green
slime or oil on
shock shaft
threads AND
O-rings to
prevent tearing
and leaking.
Note: 1.3mm
piston with
writing up.
Refer to filling
instructions on
page 19 during
this step.
Note: Do not
over-tighten
TKR6705B
*TKR6731
*TKR6732
*TKR6735
*TKR6736
*TKR6737
*TKR6738
(Option)
TKR6793
*TKR6794
*TKR6795
*TKR6796
*TKR6797
(Option)
TKR6780
Bag L
Rear Shock
Assembly
18
Stock shock position is 2nd
hole from inside on the tower
and inside hole on the arm (2/A)
Shock length (droop) is 89mm
Stock rear ride height is 20mm
