Tekno EB410.2 - P26_EB410_2 instructions_SpareParts

26
TKR6502 - EB410.2 1/10th 4WD Competition Electric Buggy Kit
Parts List
TKR5125 - O-Ring (ESC tray, 3pcs)
TKR5126 - Antenna tube (universal, w/ caps, 5pcs)
TKR5230 - Steering Linkage (M3x18mm threaded rod, 10pcs)
TKR5238 - Steering linkage (M3x30mm threaded rod, 10pcs)
TKR5571M - Wheel Hexes (12mm, steel, lightened, 4pcs)
TKR6206 - Ball Stud (5.5mm, short neck, 6mm thread, 4pcs)
TKR6207 - Ball Stud (5.5mm, long neck, 6mm thread, 4pcs)
TKR6208 - Ball Stud (5.5mm, short neck, 8mm thread, 4pcs)
TKR6212 - Ball Stud (5.5mm, short neck, 12mm thread, 4pcs)
TKR6218 - Ball Stud (5.5mm, long neck, 8mm thread, 4pcs)
TKR6250 - Turnbuckle (M3 thread, 55mm length, 4mm adjustment, 2pcs)
TKR6252 - Turnbuckle (M3 thread, 40mm length, 4mm adjustment, 2pcs)
TKR6253B - Rod End Set (turnbuckles, sway bar, steering, EB410.2)
TKR6270R - Stub Axles (rear, hardened steel, EB410, 2pcs)
TKR6274 - Wheel Nuts (7mm, serrated, gun metal ano, M4, 4pcs)
TKR6280 - Battery Strap Thumb Screw (EB410)
TKR6501B - Chassis (revised, CNC 7075, EB410.2/ET410)
TKR6519B - Bulkhead Set (f/r, revised, EB410.2/ET410)
TKR6523HD - Hinge Pins (inner, 3.5mm f/r, requires TKR6544B, 2pcs)
TKR6525B - Suspension Arms (front, for 3.5mm TKR6523HD pins)
TKR6526C - Bell Cranks, Servo Horns, Ackerman Plate (revised, EB410.2)
TKR6527B - Shock Standos (requires TKR6780, EB/ET410, 2pcs)
TKR6530 - Motor Mount Base (CNC, 7075, EB410)
TKR6538 - Chassis Brace, Body Mount Set (EB410)
TKR6539 - Motor Mount Insert (CNC, 7075, EB410)
TKR6540HD - Hinge Pin Brace (CNC, 7075, EB410.2, A Block)
TKR6541HD - Hinge Pin Brace (CNC, 7075, EB410.2, B Block)
TKR6542HD - Hinge Pin Brace (CNC, 7075, EB410.2, C Block)
TKR6543HD - Hinge Pin Brace (CNC, 7075, EB410.2, D Block)
TKR6544B - Hinge Pin Inserts, Wheelbase Shims (req TKR6523HD pins)
TKR6546B - Wing Mount and Bumper (one-piece mount, EB410.2)
TKR6547 - Sway Bar and Bulkhead Acc. (EB410)
TKR6548 - Pivot Balls (5.5mm, flanged, 4pcs)
TKR6553 - Spindles (l/r, EB410)
TKR6555 - Stabilizer Balls (5.5mm, sway bars, aluminum, 4pcs)
TKR6565 - Hinge Pins (outer, front, EB410, 2pcs)
TKR6566 - Hinge Pins (outer, rear, EB410, 2pcs)
TKR6572B - Driveshaft (rear, hardened steel, EB410.2, 2pcs)
TKR6573F - Stub Axles (front, hardened steel, EB410, 2pcs)
TKR6574B - Driveshaft (front, hardened steel, EB410.2, 2pcs)
TKR6576 - Rear Hubs (adjustable Roll Center, L/R, EB410.2)
TKR6584 - Suspension Arms (rear, forward shock mount, EB410.2)
TKR6586 - Side Guard, Servo Mount, Battery Acc. (EB410)
TKR6590 - Sway Bar Mount (rear, EB410.2)
TKR6596 - Kingpin Shoulder Screws (EB410, 4pcs)
TKR6597 - Di Coupler (f/r, lightened, hardened steel, EB410)
TKR6599 - Tapered Driveshaft (center, rear, 7075, black ano, EB410)
TKR6600 - Tapered Driveshaft (center, front, 7075, black ano, EB410)
TKR6605 - Wing (lexan, pre-cut, EB410)
TKR6608 - Body (0.8mm, EB410)
TKR6610 - Sway Bar Set (rear, 1.5, 1.6, 1.7, 1.8, 1.9mm, EB410)
TKR6623 - Sway Bar Kit (complete front, 1.0, 1.1, 1.2, 1.3, 1.4mm, EB410)
TKR6627 - Steering Rack Bushings (aluminum, EB410, 2pcs)
TKR6629B - Steering Posts (revised, steel, EB410.2, 2pcs)
TKR6634 - Center Di Support, Top Braces (EB410)
TKR6648 - Spindle Carriers (15°, LRC, L/R, EB410.2)
TKR6649 - Decal Sheet (EB410.2)
TKR6664B - Front Camber Link Plate (revised, aluminum, EB410.2)
TKR6666 - Rear Camber Link Plate (aluminum, EB410.2)
TKR6681 - Shock Tower Set (F/R, EB410.2)
TKR6685 - Rear Body Mount Panels (EB410, 2pcs)
TKR6686 - Body Mount Hook and Loop Tape Set (EB410, 4pcs)
TKR6856 - CV Rebuild kit (f/r, for 2 axles)
Dierential List
TKR5144 - Dierential O-Rings (6pcs)
TKR6511 - Dierential Case (f/c/r, 3pcs, EB410)
TKR6512 - Dierential Ring Gear (40t, use with TKR6551)
TKR6513X - Dierential Cross Pins (composite, 3pcs, EB410)
TKR6514 - Dierential Outdrives (f/r/c, lightened, EB410)
TKR6515 - Dierential Seals (3pcs, EB410)
TKR6517 - Dierential Shims (5x14mm, hardened, 6pcs, EB410)
TKR6522B - Spur Gear (revised material, 81t, 48pitch, black, EB410.2)
TKR6550 - Dierential Gear Set (internal gears only, EB410)
TKR6551 - Di Pinion (16t, use with TKR6512)
Bearings List
TKRBB040725 - Ball Bearing (4x7x2.5mm, 4pcs)
TKRBB05114 - Ball Bearing (5x11x4, 4pcs)
TKRBB06124 - Ball Bearing (6x12x4, 4pcs)
TKRBB10154 - Ball Bearing (10x15x4, 4pcs)
Shocks List
TKR6701 - Locking Shock Rod End and Spring Perch Set (13mm shocks)
TKR6703 - Shock Shafts (front, steel, EB410, 2pcs)
TKR6704 - Shock Shafts (rear, steel, EB410, 2pcs)
TKR6705B - Shock Piston Set (8x1.2, 8x1.3, flat/flat, 13mm, 4pcs)
TKR6708 - Shock Cartridge Guide Set (CNC, Delrin, 8pcs, EB410/ET410)
TKR6709 - Shock X-rings (8pcs, EB410)
TKR6710 - Shock Body (front, aluminum, hard ano, EB410, 2pcs)
TKR6711 - Shock Body (rear, aluminum, hard ano, EB410, 2pcs)
TKR6712 - Shock/Cartridge Cap & Bushing Set (4pcs each, EB410)
TKR6714 - Emulsion O-ring Set (4x cap seals, 8x emulsion o-rings, for 13mm shocks)
TKR6719A - Shock Adjustment Collars (aluminum, EB410, 2pcs)
TKR6780 - Shock Cap Bushings (requires TKR6527B, EB/ET410, 4pcs)
TKR6787 - Shock Spring Set (front, 1.3x7.75, 3.85lb/in, 45mm, red)
TKR6793 - Shock Spring Set (rear, 1.2x9.38, 2.20lb/in, 53mm, pink)
Hardware List
TKR1201 - M3 Locknuts (black, 10pcs)
TKR1211 - M3 Locknuts (flanged, black, 10pcs)
TKR1221 - M3x8mm Washer (black, 10pcs)
TKR1229 - 6x10x.2 Shims (10pcs)
TKR1235 - Body Clips (angled, 10pcs)
TKR1240 - Lower Shock Mount Screws (2 CW thread, 2 CCW thread)
TKR1245 - Shock Piston Retainer Screw (4pcs)
TKR1248 - M2x4mm Cap Head Screws (black, 10pcs)
TKR1301 - M2.5x6mm Flat Head Screws (black, 10pcs)
TKR1303 - M2.5x10mm Flat Head Screws (black, 10pcs)
TKR1321 - M3x6mm Flat Head Screws (black, 10pcs)
TKR1322 - M3x8mm Flat Head Screws (black, 10pcs)
TKR1323 - M3x10mm Flat Head Screws (black, 10pcs)
TKR1329 - M3x20mm Flat Head Screws (black, 10pcs)
TKR1400 - M3x4mm Button Head Screws (black, 10pcs)
TKR1401 - M3x6mm Button Head Screws (black, 10pcs)
TKR1402 - M3x8mm Button Head Screws (black, 10pcs)
TKR1403 - M3x10mm Button Head Screws (black, 10pcs)
TKR1405 - M3x14mm Button Head Screws (black, 10pcs)
TKR1409 - M3x20mm Button Head Screws (black, 10pcs)
TKR1411 - M3x25mm Button Head Screws (black, 10pcs)
TKR1463 - M2.5x6mm Button Head Screws (black, 10pcs)
TKR1522 - M3x8mm Cap Head Screws (black, 10pcs)
TKR1523 - M3x10mm Cap Head Screws (black, 10pcs)
TKR1601 - M3x4mm Set Screws (black, 10pcs)
TKR1602 - M4x4mm Set Screws (black, 10pcs)
TKR1604 - M3x8mm Set Screws (black, 10pcs)
TKR1609 - M3x3mm Set Screws (black, 10pcs)
TKR1611 - M4x8mm Set Screws (black, 10pcs)
Option Parts
TKR1103 - Turnbuckle Wrench (4mm, 5mm, hardened steel)
TKR1115 - Pivot Ball and Shock Multi-tool (aluminum)
TKR1119 - 5.5mm / 7.0mm Wrench (hardened steel)
TKR1654 - Composite 12mm Hex Adapters (+1mm, 4pcs)
TKR1654X - 12mm Aluminum Hex Adapters (+1mm, aluminum, 4pcs)
TKR5571 - Composite Wheel Hexes (12mm, 4pcs)
TKR5571A - Wheel Hexes (SCT410, 12mm, aluminum, 4pcs)
TKR6503C - Battery Strap (carbon fiber, EB410)
TKR6524B - Suspension Arms (rear, for 3.5mm TKR6523HD pins)
TKR6563A - Aluminum Servo Horn (25T, standard, low profile, M3 clamp, EB410)
TKR6598C - Steering Top Plate (carbon fiber, EB410)
TKR6635C - Center Di Top Plate and Fan Mount (carbon fiber, EB410)
TKR6703T - Shock Shafts (front, steel, TiNi coated, EB410, 2pcs)
TKR6704T - Shock Shafts (rear, steel, TiNi coated, EB410, 2pcs)
TKR6712A - Shock Caps (7075, emulsion, black ano, 2pcs
TKR6705 - Shock Piston Set (2x1.7, 2x1.8, flat/flat, 13mm, 4pcs)
TKR6731 - Shock Pistons (CNC, 2x1.7, 2pcs)
TKR6732 - Shock Pistons (CNC, 2x1.8, 2pcs)
TKR6735 - Shock Piston Blanks (CNC, flat/flat, 13mm, 4pcs)
TKR6736 - Shock Pistons (CNC, 8x1.1, flat/flat, 13mm, 2pcs)
TKR6737 - Shock Pistons (CNC, 8x1.2, flat/flat, 13mm, 2pcs)
TKR6738 - Shock Pistons (CNC, 8x1.3, flat/flat, 13mm, 2pcs)
TKR6783 - Shock Spring Set (front, 1.3x9.5, 2.95lb/in, 45mm, pink)
TKR6784 - Shock Spring Set (front, 1.3x9.0, 3.16lb/in, 45mm, green)
TKR6785 - Shock Spring Set (front, 1.3x8.5, 3.41lb/in, 45mm, yellow)
TKR6786 - Shock Spring Set (front, 1.3x8.13, 3.62lb/in, 45mm, orange)
TKR6794 - Shock Spring Set (rear, 1.2x8.75, 2.41lb/in, 53mm, green)
TKR6795 - Shock Spring Set (rear, 1.2x8.25, 2.6lb/in, 53mm, yellow)
TKR6796 - Shock Spring Set (rear, 1.2x7.75, 2.82lb/in, 53mm, orange)
TKR6797 - Shock Spring Set (rear, 1.2x7.38, 3.02lb/in, 53mm, red)
