Tekno EB48 2.2 - Page 8

Bag F
Rear Hub/Camber Link
8
TKR9674
TKRBB08165F
TKR1603
TKR9674
TKR9054B
*TKR9054A
(option)
TKR9054B
TKR9287
TKRBB12215
Thread
Lock
*TKR5071 (0mm)
*TKR9671 (+2mm)
*TKR5071X (light, 0mm)
*TKR5071B (light, +1mm)
*TKR5071C (light, +2mm)
(Option)
Note: Make two of these assemblies.
*TKR8073
(Option)
Grease
*TKR8072
(Option)
*TKRBB15214
(Option)
*TKR9054A/B
(In BAG Q)
*TKR8070
(Option)
*TKR8073
(Option)
Note: These parts are not included.
Optional CVD Setup
Step
F-1
Stock Rear Hub Position
TKR9054B
TKR9054A
Stock Wheelbase Position
TKR9134
TKR1201
TKR1201
TKR9056
TKR5165
TKR5165
TKR9056
Note: Repeat on other side.
TKRBB08165F
Flanged Ball Bearing (8x16x5)
x2
TKR1201
M3 Locknut Black
x4
TKRBB12215
Ball Bearing (12x21x5)
x2
Step
F-2
TKR1603
M5x4mm Set Screw
x2
