Tektronix 1103 User Manual

Specifications
This section lists t he electri
cal, environmental, and physical
characteristics of the product. The electrical characteristics listed in
the following table apply when an adjusted 1103 product is operating
within the environmental con
ditions
Table 1: Electrical characteristics
Characteristic Information
Input voltage
12 V DC, ±3VDC
Output voltage
+15 VDC
±2%
–15 VDC
±2%
+5 VDC
±2%
–5 VDC
±2%
Output current 300 mA from each supply
Power c
onsumption
30 W m ax
imum, 15 W typical
Output con figuration
TekProbe connector
Pin 1: No connection
Pin 2: No connection
Pin 3: +5 VDC
Pin 4: +15 VDC
Pin 5: Offset 1 V
Pin6:–5VDC
Pin 7: –15 VDC
1103 Power Supply Instruction Manual 9

Tektronix 1103 Specifications

General

Brand	Tektronix
Model	1103
Category	Power Supply
Language	English
