Specifications
The pinout config uratio n of the TekProbe connecto r on the front of
the product is shown below.
Table 2: Environmental characteristics
Characteristic Information
Temperature range
Operating 0 °C to +50 °C (32 °F to 122 °F)
Nonoperating
–40 °C to +70 °C (–40 °F to 158 °F )
Humidity
Operating 5% t o 95% relative humidity (% RH) at up
to +30 °C, 5% to 45% RH above +30 °C
up to +50 ° C, non-condensing
Nonoperating
5% to 95% RH (Relative Humidity) at up
to +30 °C, 5% to 45% RH above +30 °C
up to +50 ° C, non-condensing
Altitude
Operating 3,000 mete rs (~10,000 ft)
Nonoperating
15,240 meters (50,000 ft)
Table 3: Physical characteristics
Characteristic Information
Weight
1
2.0 kg (4.5 lb)
Length
16.5 cm (6.5 in)
Width
15.7 cm (6.2 in)
Height
8.9 cm (3.5 in)
1
Does not include accessories and shipping container
10 1103 Power Supply Instruction Manual
