Table 8: Rear chassis assembly with power supply and fans
Fig. &
index
number
Tektronix part
number
Serial no.
effective
Serial no.
discont'd
Qty Name & description
Figure 5 on page
38
-1 407-6131-XX 1
BRACKET, POWER SUPPLY, 750W
-2 337-4731-XX 1
SHIELD, INSULATOR, POWER SUPPLY, SAFETY CONTROLLED
-3 119-8939-XX 1 FAN WITH 2X2 CONN, 60X25MM, 12V, SAFETY CONTROLLED
-4 119-8375-XX 1 POWER SUPPLY, INTERNAL, SAFETY CONTROLLED
-5 337-4717-XX 1 SHIELD, MOUNT, POWER SUPPLY, SAFETY CONTROLLED
-6 119-8919-XX 1 FAN ASSEMBLY, SAN ACE 9GA0812P4J0011 W/ TERMINATION,
SAFETY CONTROLLED
-7 407-6151-XX 1 BRACKET, 2 FANS
-8 348-2082-XX 12 GROMMET, FAN MOUNT, NOISE DAMPING
-9 441-2902-XX 1 CHASSIS, REAR
-10 335-4011-XX 1 LABEL, REAR, IO, TOP
-11 335-4012-XX 1 LABEL, REAR, IO, BOTTOM
-12 119-8742-XX 1 FILTER, EMI, AC LINE FILTER, CHASSIS MOUNT,
FN9244R10-06, SAFETY CONTROLLED
-13
211-1584-XX
7 SCREW, MACHINE, M3X0.5X6MM PAN HEAD, TORX T10
-14 407-6130-XX 1
BRACKET, POWER SUPPLY, FAN
-15 211-1686-XX 2 SCREW, MACHINE; M3X0.5X10, FLAT HEAD, STL, TORX 10
Replaceable parts
4 Series MSO (MSO44, MSO46) Service 39
