Tektronix 760A User Manual

Operating Instructions
2–4
760A / 760D / 760N
The graticule provides calibrated reference marks for a variety of uses. Both
graticule options have the same markings and differ only in their orientation.
Figures 2–3 and 2–4 show the Sound Stage and XY graticules.
L=R
R
L
L= –R
AMPLITUDE
MARKS
PHASE
MARKS
PHASE
TANGENT
LINES
Figure 2–3: 760A Sound Stage Graticule
L
L=R
R
L= –R
PHASE
TANGENT
LINES
AMPLITUDE
MARKS
PHASE
MARKS
Figure 2–4: 760A X–Y Graticule
Graticule

Tektronix 760A Specifications

General

Brand	Tektronix
Model	760A
Category	Monitor
Language	English
