AFG1000 Series Specifications and Performance Verification
Table 19: Series Performance Test Record
Instrument Serial Number: Certificate Number:
Temperature: RH %:
Date of Calibration: Technician:
Frequency, Amplitude, DC Offset, Counter, and AC Flatness Test Record
Frequency Minimum
Test result Maximum
Sine at 1.000000 MHz 0.999999 MHz 1.000001 MHz
Pulse at 1.000000 MHz 0.999999 MHz 1.000001 MHz
Amplitude
CF = 2 / (1 + 50 Ω / Measurement Ω) =
CH1 Amplitude Minimum Test result Maximum
10 mVrms at 1.00 kHz (10 × CF - 0.454) mVrms (10 × CF + 0.454) mVrms
35 mVrms at 1.00 kHz (35 × CF – 0.704) mVrms (35 × CF + 0.704) mVrms
106 mVrms at 1.00 kHz (106 × CF – 1.41) mVrms (106 × CF + 1.41) mVrms
354 mVrms at 1.00 kHz (354 × CF – 3.89) mVrms (354 × CF + 3.89) mVrms
1.061 Vrms at 1.00 kHz (1.061 × CF - 0.0110) Vrms (1.061 × CF + 0.0110) Vrms
3.535 Vrms at 1.00 kHz (3.535 × CF - 0.0357) Vrms (3.535 × CF + 0.0357) Vrms
CH2 Amplitude Minimum Test result Maximum
10 mVrms at 1.00 kHz (10 × CF - 0.454) mVrms (10 × CF + 0.454) mVrms
35 mVrms at 1.00 kHz (35 × CF – 0.704) mVrms (35 × CF + 0.704) mVrms
106 mVrms at 1.00 kHz (106 × CF – 1.41) mVrms (106 × CF + 1.41) mVrms
354 mVrms at 1.00 kHz (354 × CF – 3.89) mVrms (354 × CF + 3.89) mVrms
1.061 Vrms at 1.00 kHz (1.061 × CF - 0.0110) Vrms (1.061 × CF + 0.0110) Vrms
3.535 Vrms at 1.00 kHz (3.535 × CF - 0.0357) Vrms (3.535 × CF + 0.0357) Vrms
DC Offset
CF = 2 / (1 + 50 Ω / Measurement Ω) =
CH1 DC Offset Minimum Test result Maximum
+5.000 Vdc (+5.000 × CF - 0.051) Vdc (+5.000 × CF + 0.051) Vdc
+2.000 Vdc (+2.000 × CF - 0.021) Vdc (+2.000 × CF + 0.021) Vdc
+1.000 Vdc (+1.000 × CF - 0.011) Vdc (+1.000 × CF + 0.011) Vdc
0.000 Vdc -0.001 Vdc +0.001 Vdc
-1.000 Vdc (-1.000 × CF - 0.011) Vdc (-1.000 × CF + 0.011) Vdc
-2.000 Vdc (-2.000 × CF - 0.021) Vdc (-2.000 × CF + 0.021) Vdc
-5.000 Vdc
(-5.000 × CF - 0.051) Vdc
(-5.000 × CF + 0.051) Vdc
