Tektronix AFG1022 Technical Reference

Specifications
AFG1000 Series Specifications and Performance Verification
9
Table 10: Modulation (cont.)
Characteristic Description
Sweep time 1 ms to 500 s ± 0.1%
Direction Up / Down
Trigger Source
Internal, External, or Manual
Burst
Waveforms Sine, Square, Ramp, Pulse, and Arbitrary
Burst count
AFG1022 1 to 50,000 cycles, infinite or gated
AFG1062
1 to 1,000,000 cycles, infinite or gated
Start Phase -360° to +360°
Trigger Sources Internal, External, or Manual
Internal trigger interval (40 ns - 500 s) ± 1%
Min = Cycles * Period
Gate Source External Trigger
Input and output specifications
Table 11: Front panel
Characteristic Description
External Reference Clock Output
Frequency 10 MHz
Impedance 50 Ω, DC coupled
Amplitude 1.6 V
p-p
into 50 Ω load
ExternalTrigger input
Level TTL compatible
Pulse width >100 ns
Slope Rising or falling (selectable)
Table 12: Rear panel
Characteristic Description
External modulation input
Input range ±1.0 V full scale (except FSK)
3.3 V logic level (FSK)
Impedance 12 kΩ (typical)
Frequency range DC to 20 kHz
External Reference Clock Input (shared with Counter input)
Impedance 400 Ω, AC coupled
Required input voltage
swing
100 mV
p-p
to 5 V
p-p
Lock range 10 MHz ± 9 kHz
