Tektronix AFG1022 Technical Reference

AFG1000 Series Specifications and Performance Verification
7
Specifications
Table 9: Output characteristics (cont.)
Characteristic Description
PV ref page
Rising/Falling Edge Time, typical
AFG1022 < 12 ns (Fixed)
AFG1062
< 10 ns (Fixed)
Overshoot, typical < 5%
Jitter (rms), typical
AFG1022 < 1 ns
AFG1062 < 500 ps
Ramp
Linearity, typical (at frequency: 1 kHz, amplitude: 1 V
p-p
, symmetry: 50%)
< 0.1% of peak output
Symmetry 0% to 100%
Noise
Type White Gaussian
Arbitrary
Rise time/fall time, typical
AFG1022 < 10 ns
AFG1062
< 8 ns
Jitter (rms), typical < 6 ns
Table 10: Modulation
Characteristic Description
AM (Amplitude Modulation)
Carrier waveforms Sine, Square, Ramp, and Arbitrary
Modulation source Internal or External
Internal modulating
waveforms
Sine, Square, Ramp, Noise, and Arbitrary
Internal modulating frequency 2 mHz to 20.0 kHz
Depth 0.0% to 100.0%
FM (Frequency Modulation)
Carrier waveforms Sine, Square, Ramp, and Arbitrary
Modulation source Internal or External
Internal modulating
waveforms
Sine, Square, Ramp, Noise, and Arbitrary
Internal modulating frequency 2 mHz to 20.0 kHz
Frequency Deviation Deviation ≤ Highest frequency of carrier waveform - Carrier waveform frequency
AFG1022 2 mHz to 12.5 MHz
AFG1062
2 mHz to 30 MHz
