Operating basics
To Output an FSK
Waveform
Frequency Shif
t Keying modulation is a modulation technique that shifts the
output signal frequency between two frequencies: the carrier frequency and Hop
frequency.
1. Follow the steps described
intheToOutp
ut an AM
Waveform procedure to display
the modulation type selection
submenu. (Se
e page 58,
Modulate a Waveform.)
In this example, select FSK as
the modulat
ion type.
2. The FSK parameter setting
screen is displayed.
Select In
ternal or External as
FSK source.
3. If you select Internal, you can set
the FSK R
ate.
If you select External, the FSK
Rate is ignored.
4. Set Hop F
requency.
Carrier w aveform frequency
shifts to the Hop frequency with
the spe
cified FSK rate, and then
returns to the original frequency.
AFG3000 and AFG3000C Series User Manual 61
