Operating basics
Invert Wavefo
rm Polarity
To invert a waveform polarity, use the Output menu. The following example
shows how to get a differential signal using the invert function of dual channel
model:
1. Select the CH1
waveform.
2. Push the front-panel
Frequency/Period button.
3. Push the Fr
equency
bezel button to set the
CH1 frequency.
4. Select the
third bezel
button from the top to
set the two channel
frequenc
ies to the same
value.
5. Push the front-panel
Channel Select button to
select C
H2.
6. Push the Output Menu
> Invert bezel buttons to
invert
the CH2 wave form.
7. Push the front-panel
CH1 Output On button to
enab
le the output.
8. You can get a differential
signal.
AFG3000 and AFG3000C Series User Manual 69
