Tektronix AFG3000C Series User Manual

Operating basics
1. After setting the CH 1
waveform parameters,
push the front
-panel
Channel select button to
select CH2.
2. Push the fr
ont-panel Top
Menu button, and then
push the Output Menu
bezel butt
on.
3. Push the CH1
Complement bezel
button.
4. The CH2 wave shape
and timing parameters
are copi
ed from CH1,
and the CH2 amplitude
settings are inverted from
CH1.
NOTE. When CH1 is selec ted in the AFG310x or AFG325x series instrument, the
instrument displays External Add Off/On in the Output menu.
AFG3000 and AFG3000C Series User Manual 73
