Operating basics
5. Save the waveform as the .tfw format.
Copy the waveform data to a USB memory
and load the wa
veform in the arbitrary function
generator.
6. The AFG300
0 series instruments output
recalled waveform data. This is an example of
the oscilloscope screen.
1
Fs repre
sents setting frequency of output waveform.
AFG3000 and AFG3000C Series User Manual 89
