Tektronix AFG3011C User Manual

Operating basics
Save/Recall I
nstrument Setup
You can save setups of the instrument as files in the internal memory or in an
external USB memory. You can recall the store d setups from a file in the internal
memory or in a
USB memory.
1. Push the front-panel
Save button
to display
the Save Menu.
2. To specify a memory
location,
select Internal
or USB. In this example,
select USB.
Use the gen
eral purpose
knob to scroll files. Push
Save to save a setting.
3. You can save a setup as
a new file i
f you specify
USB. Push Save As.
4. You c an enter a file name
in this s
creen. Use the
general purpose knob to
select a character. Push
the Ent
er Character bezel
button or the front-panel
Enter key to enter the
charac
ter.
5. To recall a setup, push
the fr
ont-panel Recall
button.
6. Select a memory location
(Inte
rnal or USB), and
then push the Recall
bezel button.
Quick Tips
You can lock a s etup file to avoid accidental overwrite. When a memory
location is locked, a lock key icon will appear on the screen. To lock or unlock
ase
tup file, push the Lock/Unlock bezel button.
To erase a file, push the Erase bezel button.
Output state is Off by default after reading a setup file.
IfyousaveasetuptoaUSBmemory,afile with the extension TFS is saved.
80 AFG3000 and AFG3000C Series User Manual
