Tektronix AFG3102 Service Manual

Specifications
1-6 AFG3000 Series Arbitrary/Function Generators Service Manual
Table 1-9: Output characteristics
Characteristics Description PV reference
page
Sine wave
✔Flatness (at 1.0 V
p-p
amplitude (+4 dBm), relative to 100 kHz) page 4-26
AFG3011 < 5 MHz: ±0.15 dB
5 MHz ≤ frq ≤ 10 MHz: ±0.3 dB
AFG3021B, AFG3022B < 5 MHz: ±0.15 dB
5 MHz ≤ frq < 20 MHz: ±0.3 dB
20 MHz ≤ frq ≤ 25 MHz: ±0.5 dB
AFG3101, AFG3102 < 5 MHz: ±0.15 dB
5 MHz ≤ frq < 25 MHz: ±0.3 dB
25 MHz ≤ frq ≤ 100 MHz: ±0.5 dB
AFG3251, AFG3252 < 5 MHz: ±0.15 dB
5 MHz ≤ frq < 25 MHz: ±0.3 dB
25 MHz ≤ frq < 100 MHz: ±0.5 dB
100 MHz ≤ frq < 200 MHz: ±1.0 dB
200 MHz ≤ frq ≤ 240 MHz: ±2.0 dB
✔Harmonic distortion (at 1.0 V
p-p
amplitude) page 4-28
AFG3011 10 Hz ≤ frq < 20 kHz: < –60 dBc
20 kHz ≤ frq < 1 MHz: < –55 dBc
1 MHz ≤ frq ≤ 10 MHz: < –45 dBc
AFG3021B, AFG3022B 10 Hz ≤ frq < 20 kHz: < –70 dBc
20 kHz ≤ frq < 1 MHz: < –60 dBc
1 MHz ≤ frq < 10 MHz: < –50 dBc
10 MHz ≤ frq ≤ 25 MHz: < –40 dBc
AFG3101, AFG3102 10 Hz ≤ frq < 1 MHz: < –60 dBc
1 MHz ≤ frq < 5 MHz: < –50 dBc
5 MHz ≤ frq ≤ 100 MHz: < –37 dBc
AFG3251, AFG3252 10 Hz ≤ frq < 1 MHz: < –60 dBc
1 MHz ≤ frq < 5 MHz: < –50 dBc
5 MHz ≤ frq < 25 MHz:< –37 dBc
25 MHz ≤ frq ≤ 240 MHz: < –30 dBc
✔Total harmonic distortion
(at 1 V
p-p
amplitude)
10 Hz to 20 kHz: < 0.2% page 4-30
