Specifications
1-8 AFG3000 Series Arbitrary/Function Generators Service Manual
Pulse
Pulse width
AFG3011 80 ns to 999.99 s
AFG3021B, AFG3022B 30 ns to 999.99 s
AFG3101, AFG3102 8 ns to 999.99 s
AFG3251, AFG3252 4 ns to 999.99 s
Resolution 10 ps or 5 digits
Pulse duty 0.001% to 99.999%
Leading edge/trailing edge
transition time
AFG3011 50 ns to 0.625 * pulse period
AFG3021B, AFG3022B 18 ns to 0.625 * pulse period
AFG3101, AFG3102 5 ns to 0.625 * pulse period
AFG3251, AFG3252 2.5 ns to 0.625 * pulse period
Resolution 10 ps or 4 digits
Overshoot, typical < 5%
Jitter (rms), typical
AFG3021B, AFG3022B,
AFG3011
500 ps
AFG3101, AFG3102 200 ps
AFG3251, AFG3252 100 ps
Ramp
Linearity (at frequency: 1 kHz, amplitude: 1 V
p-p
, symmetry: 100%)
AFG3251, AFG3252,
AFG3011
≤ 0.2% of peak output at 10% to 90% of amplitude range
AFG3021B, AFG3022B ≤ 0.1% of peak output at 10% to 90% of amplitude range
AFG3101, AFG3102 ≤ 0.15% of peak output at 10% to 90% of amplitude range
Symmetry 0% to 100%
Arbitrary
Rise time/fall time, typical
AFG3011 ≤ 80 ns
AFG3021B, AFG3022B ≤ 20 ns
AFG3101, AFG3102 ≤ 8ns
AFG3251, AFG3252 ≤ 3ns
Table 1-9: Output characteristics (cont.)
Characteristics Description PV reference
page
