Performance Verification
4-6 AFG3000 Series Arbitrary/Function Generators Service Manual
Amplitude
AFG302xB, AFG310x CF = 2 / (1 + 50 Ω / Measurement Ω) =
CH1Amplitude
30.0 mVrms at 1.00 kHz (30.0 × CF – 0.654) mVrms (30.0 × CF + 0.654) mVrms
300.0 mVrms at 1.00 kHz (300.0 × CF – 3.35) mVrms (300.0× CF + 3.35) mVrms
800.0 mVrms at 1.00 kHz (800.0 × CF – 8.35) mVrms (800.0 × CF + 8.35) mVrms
1.500 Vrms at 1.00 kHz (1.500 × CF – 0.0154) Vrms (1.500 × CF + 0.0154) Vrms
2.000 Vrms at 1.00 kHz (2.000 × CF – 0.0204) Vrms (2.000 × CF + 0.0204) Vrms
2.500 Vrms at 1.00 kHz (2.500 × CF – 0.0254) Vrms (2.500 × CF + 0.0254) Vrms
3.500 Vrms at 1.00 kHz (3.500 × CF – 0.0354) Vrms (3.500 × CF + 0.0354) Vrms
CH2 Amplitude
30.0 mVrms at 1.00 kHz (30.0 × CF – 0.654) mVrms (30.0 × CF + 0.654) mVrms
300.0 mVrms at 1.00 kHz (300.0 × CF – 3.35) mVrms (300.0× CF + 3.35) mVrms
800.0 mVrms at 1.00 kHz (800.0 × CF – 8.35) mVrms (800.0 × CF + 8.35) mVrms
1.500 Vrms at 1.00 kHz (1.500 × CF – 0.0154) Vrms (1.500 × CF + 0.0154) Vrms
2.000 Vrms at 1.00 kHz (2.000 × CF – 0.0204) Vrms (2.000 × CF + 0.0204) Vrms
2.500 Vrms at 1.00 kHz (2.500 × CF – 0.0254) Vrms (2.500 × CF + 0.0254) Vrms
3.500 Vrms at 1.00 kHz (3.500 × CF – 0.0354) Vrms (3.500 × CF + 0.0354) Vrms
AFG325x CF = 2 / (1 + 50 Ω / Measurement Ω) =
CH1 Amplitude
0.030 Vrms at 1.00 kHz (30.0 × CF – 0.654) mVrms (30.0 × CF + 0.654) mVrms
0.300 Vrms at 1.00 kHz (300.0 × CF – 3.35) mVrms (300.0× CF + 3.35) mVrms
0.800 Vrms at 1.00 kHz (800.0 × CF – 8.35) mVrms (800.0 × CF + 8.35) mVrms
1.500 Vrms at 1.00 kHz (1.500 × CF – 0.0154) Vrms (1.500 × CF + 0.0154) Vrms
CH2 Amplitude
30.0 mVrms at 1.00 kHz (30.0 × CF – 0.654) mVrms (30.0 × CF + 0.654) mVrms
300.0 mVrms at 1.00 kHz (300.0 × CF – 3.35) mVrms (300.0× CF + 3.35) mVrms
800.0 mVrms at 1.00 kHz (800.0 × CF – 8.35) mVrms (800.0 × CF + 8.35) mVrms
1.500 Vrms at 1.00 kHz (1.500 × CF – 0.0154) Vrms (1.500 × CF + 0.0154) Vrms
AFG3000 Series Performance Test Record
Minimum
Test result Maximum
