Tektronix AFG31052

Specifications
AFG31000 Series Arbitrary Function Generator Specification and Performance Verification Technical Reference 27
Characteristic Description
Resolution
1 ms or 4 digits
Total sweep time
accuracy
< 0.4%
Input and output specifications
The following tables contain input and output specifications for the AFG31000 Series.
Front panel
Table 24: Front-panel input and output specifications
Characteristic Description
Trigger input
Input level TTL compatible
Pulse width
100 ns minimum
Impedance
10 kΩ
Trigger delay
Resolution
(100 ps or 5 digits)
0.0ns to 85.000s
Trigger output
Level
Positive TTL level pulse into 1 kΩ
Impedance 50 Ω, AC coupled
Jitter (RMS), range
AFG31021, AFG31022, AFG31051,
AFG31052, AFG31101, AFG31102
10 ps
AFG31151, AFG31152 10 ps
AFG31251, AFG31252
10 ps
