Tektronix AFG31052

Test records
AFG31000 Series Arbitrary Function Generator Specification and Performance Verification Technical Reference 55
AFG31051 and AFG31052 test record
Test information
Instrument serial number:
Certificate number:
Temperature: Relative humidity %:
Date of calibration: Technician:
Frequency test record
Frequency Minimum Test result Maximum
Sine at 1.000000 MHz
0.9999984MHz
1.0000016MHz
Pulse at 1.000000 MHz 0.9999984MHz 1.0000016MHz
Amplitude test record: CH1
Calibration factor(CF)=2/(1+50Ω/MeasurementΩ)=
Amplitude Minimum Test result Maximum
3.000mV
rms
at 1.00 kHz (3.000×CF-0.384) mV
rms
(3.000×CF+0.384) mV
rms
30.000mV
rms
at 1.00 kHz (30.000×CF-0.654) mV
rms
(30.000×CF+0.654) mV
rms
300.000mV
rms
at 1.00 kHz
(300.000×CF-3.354)
mV
rms
(300.000×CF+3.354) mV
rms
800.000mV
rms
at 1.00 kHz
(800.000×CF-8.354)
mV
rms
(800.000×CF+8.354) mV
rms
1.500V
rms
at 1.00 kHz (1.500×CF-0.015) V
rms
(1.500×CF+0.015) V
rms
2.000V
rms
at 1.00 kHz (2.000×CF-0.020) V
rms
(2.000×CF+0.020) V
rms
2.500V
rms
at 1.00 kHz (2.500×CF-0.025) V
rms
(2.500×CF+0.025) V
rms
3.500V
rms
at 1.00 kHz (3.500×CF-0.035) V
rms
(3.500×CF+0.035) V
rms
