Performance verification

48 AFG31000 Series Arbitrary Function Generator Specification and Performance Verification Technical Reference

Models AFG31051, AFG31052

Function Amplitude Frequency Measurement (dB) Range (dB)

Sine

4.0 dBm

5.00 MHz

Reference ± 0.30

Sine

4.0 dBm

15.00 MHz

Reference ± 0.30

Sine

4.0 dBm

25.00 MHz

Reference ± 0.30

Sine 4.0 dBm 50.00 MHz Reference ± 0.30

Models AFG31101, AFG31102

Function Amplitude Frequency Measurement (dB) Range (dB)

Sine

4.0 dBm

1.00 kHz

= Reference

- - - - - -

Sine 4.0 dBm 1.00 MHz Reference ± 0.20

Sine 4.0 dBm 5.00 MHz Reference ± 0.30

Sine 4.0 dBm 15.00 MHz Reference ± 0.30

Sine

4.0 dBm

25.00 MHz

Reference ± 0.30

Sine

4.0 dBm

50.00 MHz

Reference ± 0.30

Sine

4.0 dBm

100.00 MHz

Reference ± 0.30

Models AFG31151, AFG31152

Function Amplitude Frequency Measurement (dB) Range (dB)

Sine

4.0 dBm

1.00 kHz

= Reference

- - - - - -

Sine

4.0 dBm

1.00 MHz

Reference ± 0.20

Sine

4.0 dBm

5.00 MHz

Reference ± 0.30

Sine 4.0 dBm 15.00 MHz Reference ± 0.30

Sine 4.0 dBm 25.00 MHz Reference ± 0.50

Sine

4.0 dBm

50.00 MHz

Reference ± 0.50

Sine

4.0 dBm

100.00 MHz

Reference ± 1.00

Sine

4.0 dBm

150.00 MHz

Reference ± 1.00

Models AFG31251, AFG31252

Function Amplitude Frequency Measurement (dB) Range (dB)

Sine

4.0 dBm

1.00 kHz

= Reference

- - - - - -

Sine

4.0 dBm

1.00 MHz

Reference ± 0.2 0

Sine

4.0 dBm

5.00 MHz

Reference ± 0.30

Sine 4.0 dBm 15.00 MHz Reference ± 0.30

Sine 4.0 dBm 25.00 MHz Reference ± 0.50

Sine 4.0 dBm 50.00 MHz Reference ± 0.50

Sine

4.0 dBm

100.00 MHz

Reference ± 1.00

Sine

4.0 dBm

150.00 MHz

Reference ± 1.00

Sine

4.0 dBm

200.00 MHz

Reference ± 2.00

Sine

4.0 dBm

250.00 MHz

Reference ± 2.00
