Specifications
Table 1-4: Analog output (cont.)
Characteristics Description
Harmonic distortion Measured with a balun.
AWG70001A and
AWG70002A
Output Frequency
2nd harmonic
<2 GHz
< –60 dBc
2GHz–6GHz
< –50 dBc
>6 GHz
< –42 dBc
3rd harmonic
<1 GHz:
< –60 dBc
1GHz–2GHz
< –50 dBc
Operating at 25 GS/s
>2 GHz
< –40 dBc
AWG70002A
Output Frequency
2nd harmonic
<1 GHz
< –60 dBc
1GHz–3.2GHz
< –55 dBc
3rd harmonic
<1 GHz:
< -60 dBc
Operating at 8 GS /s
1GHz–3.2GHz
< –50 dBc
2nd harmonic
<1 GHz
< –60 dBc
1GHz–4GHz
< –55 dBc
>4 GHz
< –50 dBc
3rd harmonic
<1 GHz:
< –60 dBc
1GHz–2GHz
< –50 dBc
Operating at 16 GS/s
>2 GHz
< –40 dBc
SFDR (See Table 1-5.)
(See Table 1-6.)
(See Table 1-7.)
(See Table 1-8.)
ENOB
AWG70001A 4.6 bits at 14.990 GHz. All noise and distortion DC - 20 GHz
AWG70002A 5.6 bits at 9.990 GHz. All noise and distortion DC - 12.5 GHz
Phase noise with jitter reduction
(See Table 1-9.)
(See Table 1-10.)
(See Table 1-11.)
(See Table 1-12.)
AWG70000A Series and AWGSYNC01 Technical Reference 1–5
