Tektronix AWG70002A

Performance tests
Performance Test Minimum Incoming Outgoing Maximum
M1 +
High level 1.185 V 1.615 V
–75 mV +75 mV
–1.065 V –0.735 V
Low level 0.735 V 1.065 V
–75 mV +75 mV
–1.615 V –1.185 V
M1 –
High level 1.185 V 1.615 V
–75 mV +75 mV
–1.065 V –0.735 V
Low level 0.735 V 1.065 V
–75 mV +75 mV
Ch2Markers
–1.615 V –1.185 V
M2 +
High le
vel
1.185 V 1.615 V
–75 mV +75 mV
–1.065 V –0.735 V
Low le
vel
0.735
V
1.065
V
–75 mV +75 mV
–1.615 V –1.185 V
M2 –
High level 1.185 V 1.615 V
–75 mV +75 mV
–1.
065 V
–0.
735 V
Low level 0.735 V 1.065 V
–75 mV +75 mV
–
1.615 V
–
1.185 V
AWG70000A Series and AWGSYNC01 Technical Reference 2–37
