Specications
Table 1: Analog channel input and vertical specications (cont.)
Characteristic Description
Measurement type
DC Accuracy (in volts)
Average of 16 waveforms ±[DC gain accuracy) × |reading - (offset - position)|
+ Offset A ccuracy]
Delta Volts between any two averages of 16
waveforms acquired with the same oscilloscope
setup and ambient conditions
±[DC gain accuracy × |reading|]
DC voltage
measurement
accuracy, Average
acquisition mode,
typical
Note: Offset, position, and the constant offset term must be converted to volts by multiplying by the
appropriate volts/div term.
The basic accuracy specication applies directly to any sample and to the following measurements: High,
Low, Max, and Min. The delta volt accuracy specication applies to subtractive calculations involving
two of these measurements.
The delta volts (difference voltage) accuracy specication applies directly to the following measurements:
Positive Overshoot, Negative Overshoot, Pk-Pk, and Amplitude.
Volts/div setting Offset range
2 m V/div to 200 mV/div
±1 V
Vertic
al offset
ranges
>200 mV/div to 5 V/div
±25 V
Vertical offset
accuracy
±[0.01 × |offset - position| + DC Balance]
Note: Both the position and constant offset term must be converted to v olts by multiplying by the
appropriate volts/div term.
Tab
le 2: Digital channel input specications, MSO2000 only
Characteristic Description
Th
reshold voltage range
-20 V to +20 V, selectable in two groups of 8
Digital threshold accuracy
±[100 mV + 3% of the threshold setting after calibration]
Digital channel timing resolution,
sample rate
1 ns when the lower ordered group of 8 inputs on the digital probe cable are used exclusively
2 ns whenever inputs from the upper ordered group of 8 inputs on the digital probe cable are
used. That is, all 16 digital channels would be sampled at 2 ns intervals
Min Detectable Pulse, typical
5ns
Number of Input Channels
16 Digital Inputs
Input Resistance, typical
101 k to ground
Input Capacitance, typical
8pF
Min Input Signal Swing, typical
500 mV
p-p
Max Input Signal Swing, typical
±20 V, centered on the threshold voltage
Peak Input Voltage Range (DC +
Peak AC)
±40 V
Digital Channel to Digital Channel
Skew
2 ns, typical
3ns,maximum
DPO2000 and MSO2000 Series Specications and Performance Verication 3
