Specications
Table 4: Trigger specications (cont.)
Characteristic Description
Time range for pulse width or runt
triggering
4nsto8s
The digital inputs d o not support the runt trigger type
Time accuracy for Pulse Width
triggering
±2 ns
Time Resolution, Logic Type
Triggers
1ns
Trigger Frequency Counter Provides the user a higher accuracy means of identifying the frequency of trigger signals.
Averaging takes place over a longer time span, so the number of stable digits is improved
over the Automatic Measurement of the same type
Trigger Frequency Counter
Resolution
6digits
Trigger Frequency Counter Accuracy ±25 ppm including all reference errors and ±1 count errors
Trigger Frequency Counter
Frequency Range
AC coupled, 10 Hz minimum to rated bandwidth
Trigger Frequency Counter Signal
Source
Edge selected trigger source only
1
For Logic, time between channels refers to the length of time a logic state derived from more than one channel must exist to be recognized. For Events, thetime
is the minimum time between a main and delayed event that will be recognized if more than one channel is used.
Table 5: Display specications
Cha
racteristic
Desc
ription
Display type
Dis
play area: 154.8 mm (6.09 inches) (H) x 87.05 mm (3.43 inches) (V), 180 mm (7.0 inches)
diagonal, 6-bit RGB full color, WQVGA (480 x 234) TFT liquid crystal display (LCD).
Di
splay resolution
48
0 horizontal by 234 vertical displayed pixels
Luminance, typical
Ma
ximum 400 cd/m
2
Table 6: Input/Output port specications
Characteristic Description
Ethernet interface Available as an optional accessory: DPO2CONN module
USB interface 1 High Speed 2.0 Host and 1 High Speed Device connector (all models)
GPIB interface Available as an optional accessory that connects to USB Device and USB Host ports:
TEK-USB-488 GPIB to USB Adapter.
Control interface is incorporated in the instrument user interface.
Video signal output
Available as an optional accessory: DPO2CONN module
A 15 pin, VGA RGB-type connector
Probe compensator output voltage
and frequency, typical
Output voltage: 0 V to 5 V ±10%
Frequency: 1 k Hz ±25%
DPO2000 and MSO2000 Series Specications and Performance Verication 7
