Acquire the Signal
7. Push Even t Table and select On to display a
listofI
2
C, SPI, CAN, or LIN bus packets with
timestamps.
Event
Table
On |O ff
Save Event
Table
For a clocked parallel bus, the table lists the
value of the bus at each clock edge. For an
unclocked parallel bus, the table lists the value
of the bus whenever any one of its bits change s.
For an RS-232 bus, the table lists decoded
bytes, or packets.
8. Push Save Event Table to save the event table
data in a .csv (spreadsheet) formatted file on
the currently selected storage device.
DPO2000 and MSO2000 Series Oscilloscopes User Man ual 99
