Tektronix DPO2012 User Manual

Analyze Waveform Data
Amplitude Measurements (cont.)
Measurement Description
Cycle RMS The true Ro ot Mean Square voltage over the first cycle in the waveform or the first cycle
in the gated region.
Miscellaneous Measurements
Measurement Description
Positive Pulse
Count
The number of positive pulses that rise above the mid reference crossing in the wavefo rm
or gated region.
Negative Pulse
Count
The number of negative pulses that fall below th e m id referenc e crossing in the wavefo rm
or gated region.
DPO2000 and MSO2000 Series Oscilloscopes User Man ual 179
