Tektronix DPO2024 Programmer's Manual

Commands Listed in Alphabetical Order
Syntax
CH<x>:IMPedan
ce
CH<x>:IMPedance?
CH<x>:INVert
Sets or returns the invert function for channel <x>, where is the channel number.
When on, the invert function inverts the waveform for the specified channel.
NOTE. This c
ommand inverts the waveform for display purposes only. The
oscilloscope does not use an inverted waveform for triggers or trigger logic inputs.
Group
Vertical
Syntax
CH<x>:INVert {ON|OFF}
CH<x>:INVert?
Arguments
OFF sets the invert function for channel <x> to off.
ON sets the invert function for channel <x> to on.
Examples
CH4:INVert ON inverts the waveform on channel 4.
CH2:INVert? might return :CH2:INVERT 0 indicating that channel 2 is not
inverted.
CH<x>:LABel
Sets or returns the waveform label for channel <x>, where x is the channel number.
Group
Vertical
Syntax
CH<x>:LABel <Qstring>
CH<x>:LABel?
Arguments
<Qstring> is an alpha-numeric string of text, enclosed in quotes, that contains
the text label information for the c hannel <x> waveform. The text string is limited
to 30 characters.
MSO2000B, DPO2000B, MSO2000 and DPO2000 Series Oscilloscopes Programmer Manual 2-101
