Command Groups
Table 2-32: Ve rtical Commands (cont.)
Command Description
CH<x>:PRObe:ID:SERnumber? Returns the serial number of the probe that
is attached to the specifi ed channel
CH<x>:PRObe:ID:TYPE? Returns the type of probe that is attached to
the specified channel
CH<x>:PRObe:RESistance? Returns the resistance of the probe that is
attached to the specified channel
CH<x>:PRObe:SIGnal Sets or returns the input bypass setting of
channel <x>TekVPI probe
CH<x>:PRObe:UN Its? Returns the units of measure of the probe
that is attached to the specified channel
CH<x>:SCAle Sets or returns the vertical scale of the
specified channel
CH<x>:TERmination Sets or returns channel input termination
CH<x>:VOLts Sets or returns the vertical sensitivity for
channel <x>
CH<x>:YUNits Sets or returns the units for the specified
channel to a custom string
REF<x>? Returns reference waveform data for channel
<x>
REF<x>:DATE? Returns the date that a reference waveform
was stored
REF<x>:HORizontal:DELay:TIMe Sets or returns the horizontal position of the
specified reference waveform in percent of
the waveform that is displayed to the right of
the center vertical graticule
REF<x>:HORizontal:SCAle Sets or returns the horizontal scale for a
reference waveform
REF<x>:LABel
Sets or returns the specified reference
waveform label
REF<x>:POSition Sets or returns the vertical position for
channel <x>, where x is the reference
channel number
REF<x>:TIMe? Returns the time that a r eference waveform
was stored
REF<x>:VERTical:POSition Sets or returns the vertical position of the
specified reference waveform
REF<x>:VERTical:SCAle Sets or returns the reference waveform
vertical scale in vertical units/div
SELect Returns information on which waveforms are
on or off and which w aveform is selected.
MSO2000B, DPO2000B, MSO2000 and DPO2000 Series Oscilloscopes Programmer Manual 2-49
