Save and Recall Information
1. Push Save / Recall Menu.
2. Push Save Waveform or Rec all Waveform
from the lower-bezel menu.
Save
Screen
Save
Waveform
Save S etup
Recall
Waveform
Recall
Setup
Assign
Save|to
Waveform
File Utilities
NOTE. The oscilloscope can save digital
waveforms to .csv files, not reference memories.
The oscilloscope cannot re call digital wavefo rms.
3. Select one waveform or all waveforms.
4. From the resulting side-bezel menu, select the
location to save the waveform data to or to
recall it from.
Save the information externally to a file
onaUSBflash drive. Alternatively, save
the information internally to one of the two
reference memory files.
DPO2000 and MSO2000 Series Oscilloscopes User Man ual 217
