Acquire the Signal
5. Use multipurpose kno b a to set the number of
bits of the SPI Word Size.
Word Size
(a) 8 bits
6. Push either side bezel button to set the bit
order of the SPI bus.
Bit Order
MS First
Bit Order
LS First
To acquire data from a CAN bus, you need to also set up these items:
1. If you selected CAN,pushDefine Inputs and
the appropriate side-bezel menu choices.
Bus
CAN
Define
Inputs
Thresholds B it Rate
500 Kbps
B1 Label
CAN
Bus Display Event Table
MSO4000 and DPO4000 Series Oscilloscopes User Manual 113
