Acquire the Signal
6. Push Bit Rate, and tu rn multipurpose knob a
to select from the list of predefined bit rates.
Alternately, you can set the bit rate to a specific
value. To do so, select Custom, and then turn
multipurpose knob b tosetthebitratefrom
800 bps to 100,000 bps.
Bit Rate
(a)
19.2K bps
7. Push LIN Standard, and turn multipurpose
knob a to select the appropriate standard.
LIN
Standard
v1.x
8. Push Includ e Parity Bits w ith Id to select
whether or not to include parity bits.
Include
Parity Bits
with Id
On|
Off
To acquire data from a RS-232 bus, y ou need to also set up these items:
MSO4000 and DPO4000 Series Oscilloscopes User Manual 117
