Analyze Waveform Data
Amplitude Measurements (cont.)
Measurement Description
Cycle RMS The true Ro ot Mean Square voltage over the first cycle in the waveform or the first cycle
in the gated region.
Miscellaneous Measurements
Measurement Description
Rising Edge
Count
The number of positive tra nsitions from the low reference value to the high reference value
in the waveform or gated region.
Falling Edge
Count
The number of negative transitions from the high reference value to the low referen ce value
in the waveform or gated region.
MSO4000 and DPO4000 Series Oscilloscopes User Manual 197
