Application E xamp les
2. Push Type.
Type
3. Turn multipurpose knob a to scroll through the
trigger type side menu until you select Video.
Video
4. Push Video Standard, and turn multipurpose
knob a to scroll through th e standards until you
select 525/NTSC.
Type
Video
Video
Standard
525/NTSC
Source
1
Trigger On
All Lines
Mode
Auto
& Holdoff
5. Push Trigger On.
