The term under the square-root sign is the stability and is due to TIE (Time Interval Error). The
errors due to this term occur throughout a single-shot measurement. The second term is due to
both the absolute center-frequency accuracy and the center-frequency stability of the time base
and varies between multiple single-shot measurements over the observation interval (the amount of
time from the first single-shot measurement to the final single-shot measurement).
The observation interval may not exceed 1 year.
Trigger specifications
Aux in external trigger input
impedance, typical
1 M Ω ±1% in parallel with 13 pF ±2 pF
Aux in (external) trigger maximum
input voltage
The maximum input voltage at the BNC 300 VRMS
Installation Category II
Derate at 20 dB/decade above 3 MHz to 30 VRMS at 30 MHz, 10 dB/decade above 30 MHz.
Aux in external trigger bandwidth,
typical
250 MHz ±20%
Trigger bandwidth, edge, typical
MSO5204/B, DPO5204/B 2 GHz
MSO5104/B, DPO5104/B 1 GHz
MSO5054/B, DPO5054/B 500 MHz
MSO5034/B, DPO5034/B 350 MHz 350 MHz
Trigger bandwidth, pulse and
logic, typical
MSO5204/B, DPO5204/B 1 GHz
MSO5104/B, DPO5104/B 1 GHz
MSO5054/B, DPO5054/B 500 MHz
MSO5034/B, DPO5034/B 350 MHz
