Digital acquisition specifications MSO5000/B series
Threshold voltage range -40 V to +40 V
Digital channel timing resolution 2 ns main memory, 60.6 ps for MagniVu memory
Logic threshold accuracy ±(100 mV + 3% of threshold setting after calibration)
Requires valid SPC.
Minimum detectable pulse width 1 ns
Using MagniVu memory. Requires the use of 342-1140-00 ground clip per channel.
P6616 digital probe specifications
Number of channels 16 digital inputs
Input resistance, typical 100 kΩ to ground
Input capacitance, typical 3.0 pF
Measured at the podlet input. Requires the use of 342-1140-00 ground clip per channel
Minimum input signal swing 400 mVp-p
Requires the use of 342-1140-00 ground clip per channel
Maximum input signal swing 30 Vp-p for fin ≤ 200 MHz (centered around the DC threshold voltage) at the P6616 probe tip.
10 Vp-p for fin >200 MHz (centered around the DC threshold voltage) at the P6616 probe tip.
Failure to meet this input signal requirement will compromise the AC performance of the digital
channel. It might also damage the input circuitry. See the Absolute maximum input voltage
specification.
Maximum input toggle rate 500 MHz
Maximum frequency sine wave input that can accurately be reproduced as a logic square wave.
Requires the use of a 342-1140-00 ground clip on each channel.
This is the maximum frequency at the minimum swing amplitude. Higher toggle rates can be
achieved with higher amplitudes.
Absolute maximum input voltage ±42 V peak at the P6616 input (not at the instrument input)
Probe input voltages beyond this limit could permanently damage the instrument and the P6616
probe.
Channel-to-channel skew 200 ps
Digital channel to digital channel only.
Specifications (MSO/DPO5000/B Series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 93
