14. Adapter (four required)
Male N-to-female BNC Tektronix part number
103-0045-00
Checking analog bandwidth
15. Adapter
Female N-to-male BNC Tektronix part number
103-0058-00 (4 GHz)
Checking analog bandwidth
16. Adapter (three required)
SMA female-to-female Tektronix part number
015-1012-00 (18 GHz)
Checking trigger sensitivity
17. Adapter (three required)
SMA male-to-female BNC Tektronix part number
015-1018-00
Checking the delay between
channels, delta time
18. Adapter
BNC to Minigrabber Tektronix part number
013-0342-xx
Checking probe compensation
output
19. Adapter (four required)
Instrument bandwidth
≤20 GHz:SMA male-to-BNC
female
TCA-BNC or TCA-292mm
and, if required, SMA male-to-
BNC female adapter
(Tektronix part number
015-0554-00 (4 GHz) or
015-1018-00)
Signal interconnection,
measurement accuracy, delay
time, time qualified trigger,
trigger sensitivity, DC gain,
offset, bandwidth, input
resistance, probe
compensation out, baud rate
limit, clock recovery
Instrument bandwidth
>20 GHz
TCA-292D
20. Pulse Generator
250 MHz, ≤ 150 ps rise time,
5 V out
Fluke 9500B
1, 2
Checking delta time
measurement accuracy
21. Cable, Coaxial (three required)
50 Ω, 20 in, male-to-male
SMA connectors
Tektronix part number
174-1427-00
Checking delta time
measurement accuracy, probe
compensation out, trigger
sensitivity
2
For Delta Time Measurement Accuracy, use a Fluke 9500B or a pulse generator with the rise time specified in the procedure.
Performance verification (MSO/DPO70000C, MSO/DPO70000DX, and DPO7000C series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 119
