Tektronix DPO5000 Series Technical Reference

Delta Time Measurement Accuracy
Sample rate = 10 GS/s, 4 ns/Div, Source freq = 240 MHz
MSO/DPO V/Div Source V
pp
Test result High limit
1 mV 8 mV NA
5 mV 40 mV 65 ps
100 mV 800 mV 61 ps
500 mV 4 V 61 ps
1 V 4 V 70 ps
Sample rate = 5 GS/s, 40 ns/Div, Source freq = 24 MHz
1 mV 8 mV 708 ps
5 mV 40 mV 322 ps
100 mV 800 mV 236 ps
500 mV 4 V 233 ps
1 V 4 V 417 ps
Sample rate = 5 GS/s, 400 ns/Div, Source freq = 2.4 MHz
1 mV 8 mV 6.68 ns
5 mV 40 mV 3.00 ns
100 mV 800 mV 2.06 ns
500 mV 4 V 2.02 ns
1 V 4 V 4.01 ns
Sample rate = 2.5 GS/s, 4 μs/Div, Source freq = 240 kHz
1 mV 8 mV 69.8 ns
5 mV 40 mV 30.0 ns
100 mV 800 mV 20.6 ns
500 mV 4 V 20.2 ns
1 V 4 V 40.1 ns
Sample rate = 200 MS/s, 40 μs/Div, Source freq = 24 kHz
1 mV 8 mV 698 ns
5 mV 40 mV 300 ns
100 mV 800 mV 206 ns
500 mV 4 V 202 ns
1 V 4 V 401 ns
Sample rate = 20 MS/s, 400 μs/Div, Source freq = 2.4 kHz
1 mV 8 mV 6.98 μs
5 mV 40 mV 3.00 μs
100 mV 800 mV 2.06 μs
500 mV 4 V 2.02 μs
1 V 4 V 4.01 μs
MSO/DPO5204/B Channel 4
Performance verification (MSO/DPO5000/B series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 305
