Tektronix DPO5000 Series Technical Reference

Delta Time Measurement Accuracy
Sample rate = 5 GS/s, 4 ns/Div, Source freq = 240 MHz
MSO/DPO V/Div Source V
pp
Test result High limit
1 mV 8 mV NA
5 mV 40 mV 118 ps
100 mV 800 mV 117 ps
500 mV 4 V 117 ps
1 V 4 V 122 ps
Sample rate = 5 GS/s, 40 ns/Div, Source freq = 24 MHz
1 mV 8 mV 464 ps
5 mV 40 mV 276 ps
100 mV 800 mV 234 ps
500 mV 4 V 232 ps
1 V 4 V 417 ps
Sample rate = 2.5 GS/s, 400 ns/Div, Source freq = 2.4 MHz
1 mV 8 mV 4.50 ns
5 mV 40 mV 2.52 ns
100 mV 800 mV 2.05 ns
500 mV 4 V 2.03 ns
1 V 4 V 4.01 ns
Sample rate = 250 MS/s, 4 μs/Div, Source freq = 240 kHz
1 mV 8 mV 45.0 ns
5 mV 40 mV 25.2 ns
100 mV 800 mV 20.5 ns
500 mV 4 V 20.3 ns
1 V 4 V 40.1 ns
Sample rate = 25 MS/s, 40 μs/Div, Source freq = 24 kHz
1 mV 8 mV 450 ns
5 mV 40 mV 252 ns
100 mV 800 mV 205 ns
500 mV 4 V 203 ns
1 V 4 V 401 ns
Sample rate = 2.5 MS/s, 400 μs/Div, Source freq = 2.4 kHz
1 mV 8 mV 4.50 μs
5 mV 40 mV 2.52 μs
100 mV 800 mV 2.05 μs
500 mV 4 V 2.03 μs
1 V 4 V 4.01 μs
MSO/DPO5054/B and MSO/DPO5034/B Channel 1
Performance verification (MSO/DPO5000/B series)
310 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
