Seconds division range ≥4 GHz models, Fastest sweep speed is 20 ps per division
<4 GHz models
DPO7354
C,
DPO7254
C
Record
Length
Horizontal
mode
1 K 10 K 100 K 1 M 10 M 100 M 400/500 M
Automatic 25 ps -
20 s
250 ps -
200 s
2.5 ns -
1ks
50 ns -
1 ks
500 ns -
1 ks
5 us - 1 ks 5 us - 1 ks
Constant
SR
25 ps -
20 s
250 ps -
200 s
2.5 ns -
1ks
50 ns -
1 ks
500 ns -
1 ks
5 us - 1 ks 10 us -
1 ks
Manual 25 ps -
40 s
250 ps -
400 s
2.5 ns -
4ks
25 ns -
40 ks
250 ns -
400 ks
2.5 us -
4 Ms
12.5 us -
8.19 Ms
DPO7104
C,
DPO7054
C
Record
Length
Horizontal
mode
1 K 10 K 100 K 1 M 10 M 100 M 200/250 M
Automatic 25 ps -
20 s
250 ps -
200 s
2.5 ns -
1ks
50 ns -
1 ks
500 ns -
1 ks
5 us - 1 ks 5 us - 1 ks
Constant
SR
25 ps -
20 s
250 ps -
200 s
2.5 ns -
1ks
50 ns -
1 ks
500 ns -
1 ks
5 us - 1 ks 10 us -
1 ks
Manual 25 ps -
40 s
250 ps -
400 s
2.5 ns -
4ks
25 ns -
40 ks
250 ns -
400 ks
2.5 us -
4Ms
5 us - 8 Ms
Acquisition update rate, typical
≥4 GHz models Fast Acquisition on: 300,000 waveforms per second maximum
<4 GHz models Fast Acquisition on: 250,000 waveforms per second maximum
Time base delay time range 5 ns to 250 s
Internal time-base reference
frequency
10 MHz
Electronically adjustable over about ±5 ppm.
Long term sample rate
accuracy
<4 GHz models ± 2.5 ppm initial accuracy. Aging < 1 ppm per year. Applies only when using the internal reference.
≥4 GHz models ± 1.5 ppm initial accuracy. Aging < 1 ppm per year. Applies only when using the internal reference.
Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C series) Horizontal and acquisition system
(cont.)
50 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
