Tektronix DPO5000 Series Technical Reference

Width and glitch trigger sensitivity,
typical
≥4 GHz models 15% x FS from DC to 1 GHz, not violating the minimum timing requirements for each type (for
vertical settings from 10 mV/div to 1 V/div at the input connector)
<4 GHz models 1.0 division from DC to 1 GHz (at input connector)
Width and glitch trigger minimum
timing requirements
For vertical scale settings 10 mV/div and 1 V/div
≥4 GHz models
Minimum
pulse width
Minimum
rearm time
Setup time Hold time
Width and glitch types 150 ps 300 ps N.A. N.A.
Logic qualified width and glitch
types
150 ps 300 ps 20 ps 40 ps
<4 GHz models
Minimum
pulse width
Minimum
rearm time
Setup time Hold time
Width type 225 ps 250 ps N.A. N.A.
Logic qualified width type 190 ps 250 ps 40 ps 175 ps
Glitch type 170 ps 250 ps N.A. N.A.
Logic qualified glitch type 100 ps 250 ps 40 ps 60 ps
Runt trigger sensitivity, typical
≥4 GHz models 15% x FS from DC to 1 GHz, not violating the minimum timing requirements for each type (for
vertical settings from 10 mV/div to 1 V/div at the input connector)
<4 GHz models 1.0 division (at input connector)
Runt trigger, minimum timing
requirements
A runt event occurs at the end of the runt whether or not the runt was time qualified. Logic qualified
runt triggers require that the logic condition be true during the entire duration of the runt plus some
minimum amount of time after the runt event occurred.
≥4 GHz models
Minimum
pulse time
Minimum
rearm time
Setup time Hold time
Runt type 200 ps 300 ps
Logic qualified runt type 200 ps 300 ps 300 ps 300 ps
Time qualified runt type 476 ps 510 ps N.A. N.A.
Time and logic qualified runt
type
520 ps 360 ps 160 ps 105 ps
<4 GHz models
Minimum
pulse time
Minimum
rearm time
Setup time Hold time
Runt type 225 ps 250 ps N.A. N.A.
Time qualified runt type 360 ps 450 ps N.A. N.A.
Logic qualified runt type Runt width +
150 ps
250 ps 160 ps -16 ps
Time and logic qualified runt
type
Runt width +
330 ps
250 ps 160 ps 175 ps
Trigger specifications (cont.) Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 61
