Tektronix DPO5000 Series Technical Reference

Clock recovery jitter, typical
≥4 GHz models < 0.25% bit period + 2 ps rms for PRBS data patterns with 50% transition density.
< 0.25% bit period + 1.5 ps rms for repeating 0011 data patterns.
Bit rate Pattern Jitter (ps rms)
PRBS 0011
3.125 GBd 00110011 2.8 ps 2.3 ps
2.74 GBd 00110011 2.9 ps 2.4 ps
2.35 GBd 00110011 3.1 ps 2.6 ps
2.34 GBd 00110011 3.1 ps 2.6 ps
1.95 GBd 00110011 3.3 ps 2.8 ps
1.57 GBd 00110011 3.6 ps 3.1 ps
100 MBd 00110011 27 ps 27 ps
10 MBd 00110011 252 ps 252 ps
<4 GHz models 20 ps
RMS
+ 1.25% Unit interval RMS for PRBS data patterns.
20 ps
RMS
+ 1.25% Unit interval RMS for repeating 0011 data patterns. (Transition density of 50%).
Jitter increases by 1.4 every time the transition density is reduced by half.
28 ps
RMS
+ 1.25% Unit interval RMS for 25% transition density.
30 ps
RMS
+ 1.25% Unit interval RMS for 12.5% transition density.
Clock recovery tracking
acquisition range
≥4 GHz models ± 2% of requested baud, data rates below 1.25 GBaud.
± 0.25% of requested baud, data rates above 1.25 GBaud.
<4 GHz models ± 5% of requested baud
Minimum signal amplitude needed
for clock recovery, typical
≥4 GHz models 1 division peak-peak up to 1.25 GBd
1.5 divisions peak-peak above 1.25 GBd
Tri-level signals need 50% more pk-pk amplitude
<4 GHz models 1 division peak-peak up to 1.25 GBd
50% more peak-to-peak amplitude is required for tri-level signals.
Serial interface triggering
standards supported
<4 GHz models I
2
C, CAN, SPI, USB1.1, RS232/422/485/UART
Serial trigger specifications (cont.) Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 67

Tektronix DPO5000 Series Specifications
