Tektronix DPO5000 Series Technical Reference

High speed serial data output
latency, typical
≥4 GHz models 11 ns ± 4 ns, plus the following synchronous latency depending on the data encoding:
35.5 clock cycles for NRZ, CMI, Manchester, and B-0-V decoded data.
36.5 clock cycles for NRZI decoded data.
39.5 clock cycles for B3ZS decoded data.
40.5 clock cycles for B4ZS decoded data.
42.5 clock cycles for B6ZS decoded data.
44.5 clock cycles for B8ZS decoded data.
Probe compensation output
step amplitude and offset
>20 GHz models 440 mV ± 22% into a 50 Ω load (Vol = -0.14 V, Voh = 0.3 V, typical)
810 mV ± 22% into a ≥10 kΩ load, (Vol = -0.25 V, Voh = 0.56 V, typical)
≥4 GHz, ≤20 GHz models 440 mV ± 22% into a 50 Ω load (Vol = -0.2 V to 0 V, Voh = 0.2 V to 0.4 V, typical)
810 mV ± 22% into a 10 kΩ load, (Vol = -0.4 V to 0 V, Voh = 0.4 V to 0.8 V)
<4 GHz models 1 V ± 1.5% into a ≥ 100 kΩ load (Vol = -1.0 V, Voh = 0 V typical)
Add 0.05%/°C for temperatures greater than or less than 25 °C
Probe compensation output step
frequency
≥4 GHz models 1 kHz ± 20%
<4 GHz models 1 kHz ± 5%
Probe calibration output step rise
time
≥4 GHz models 300 ps (10% to 90%) directly into an input channel. To deskew a probe, use a 50 Ω terminator in
series with the deskew fixture to minimize HF aberrations.
<4 GHz models ≤350 ps at 1 V, into a ≥20 KΩ load to ground.
≤1 ns at 2 V, into a 50 Ω load to ground.
To deskew a probe, use a 50 Ω terminator in series with the deskew fixture to minimize HF
aberrations.
Probe calibration output step
aberrations
≤ ± 1% after the first 500 ns following the square wave transition. To deskew a probe, use a 50 Ω
terminator in series with the deskew fixture to minimize HF aberrations.
Jitter of internal probe calibration
trigger
5 ps RMS
External reference input frequency,
typical
Run SPC whenever the external reference is more than 0.1% (1000 ppm) different than the
nominal reference or the reference at which SPC was last run.
Input-output port specifications (cont.) Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C
series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 71
