Tektronix DPO70000C/DX Series Technical Reference

Offset range
>20 GHz models
Full Scale voltage range Offset range
62.5 mV
FS
– 1.2 V
FS
±3.4 V
>1.2 V
FS
– 6 V
FS
±6 V
≥4 GHz, ≤20 GHz models Offset is reduced to allow for position control according to the following formulas:
10 mV/div to 99.5 mV/div: Offset range = ±(0.5 V - (V/div setting × 5 div))
100 mV/div to 500 mV/div: Offset range = ±(2.5 V - (V/div setting × 5 div))
SCALE range Offset range
10 mV/div ±0.450 V
12 mV/div ±0.440 V
14 mV/div ±0.430 V
16 mV/div ±0.420 V
18 mV/div ±0.410 V
19.9 mV/div ±0.4005 V
20 mV/div ±0.400 V
30 mV/div ±0.350 V
40 mV/div ±0.300 V
49.8 mV/div ±0.251 V
50 mV/div ±0.250 V
60 mV/div ±0.200 V
70 mV/div ±0.150 V
80 mV/div ±0.100 V
90 mV/div ±0.050 V
99.5 mV/div ±0.0025 V
100 mV/div ±2.00 V
120 mV/div ±1.90 V
140 mV/div ±1.80 V
160 mV/div ±1.70 V
200 mV/div ±1.50 V
248 mV/div ±1.260 V
250 mV/div ±1.250 V
300 mV/div ±1.00 V
400 mV/div ±0.50 V
500 mV/div ±0.00 V
Vertical system analog channels (cont.) Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C
series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 7
