<4 GHz models, 50 Ω coupling
SCALE range Offset range
1 mV/div to 50 mV/div ±1.0 V
50.5 mV/div to 99.5 mV/div ±1.5 V - 10 divisions
100 mV/div to 500 mV/div ±10 V
505 mV/div to 1 V/div ±15 V - 10 divisions
<4 GHz models, 1 MΩ
coupling
SCALE range Offset range
1 mV/div to 50 mV/div ±1 V
50.5 mV/div to 99.5 mV/div ±1.5 V - 10 divisions
100 mV/div to 500 mV/div ±10 V
505 mV/div to 995 mV/div ±15 V - 10 divisions
1.0 V/div to 5 V/div ±100 V
5.05 V/div to 10 V/div ±150 V - 10 divisions
Offset accuracy Net offset = offset - (position × volts/division).
>20 GHz models
Full scale voltage range Offset accuracy
62.5 mV
FS
to 1.2 V
FS
±(0.4% | net offset | + 0.2% | net offset – Vterm
setting | + 2.5 mV + 1% Full Scale)
>1.2 V
FS
to 6 V
FS
±(0.6% | net offset | + 13.4 mV + 1% Full Scale)
≥4 GHz, ≤20 GHz models
SCALE range Offset accuracy Temperature variation
10 mV/div to 99.5 mV/div ±(0.35% × | net offset | +
1.5 mV + 1% x Full Scale)
100 mV/div to 0.5 V/div ±(0.35% × | net offset | +
7.5 mV + 1% x Full Scale)
±(0.45% × | offset | /°C)
<4 GHz models
SCALE range Offset accuracy
1 mV/div to 9.95 mV/div ±(0.2% × | net offset | + 1.5 mV + 0.1 div × V/div
setting)
10 mV/div to 99.5 mV/div ±(0.35% × | net offset | + 1.5 mV + 0.1 div × V/
div setting)
100 mV/div to 1 V/div ±(0.35% × | net offset | + 15 mV + 0.1 div × V/
div setting)
1.01 V/div to 10 V/div ±(0.25% × | net offset | + 150 mV + 0.1 div
× V/div setting)
Analog bandwidth >20 GHz
models
Bandwidth with a TCA292D adapter.
Operating ambient temperature <30 °C. Use the Temperature variation table to determine the
amount of performance derating above the temperature limit.
Enhanced bandwidth only applies to full scale (FS) stepped gain settings of 62.5 mV, 100 mV,
200 mV, 500 mV, 1 V, 2 V, and 5 V.
Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C series) Vertical system analog channels
(cont.)
8 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
