The MSO/DPO73304DX, MSO/DPO72504DX, and MSO/DPO72304DX instrument bandwidths
with BWE disabled are typical.
MSO/DPO73304DX
BW settings Bandwidth Sample rate
No BWE DC to >33 GHz, typical All
33 GHz BWE DC to >33 GHz 100 GS/s
23 GHz BWE DC to >23 GHz 50 GS/s
MSO/DPO72504DX
BW settings Bandwidth Sample rate
No BWE DC to >25 GHz, typical All
25 GHz BWE DC to >25 GHz 100 GS/s
23 GHz BWE DC to >23 GHz 50 GS/s
MSO/DPO72304DX
BW settings Bandwidth Sample rate
No BWE DC to >23 GHz, typical 50, 100 GS/s
23 GHz BWE DC to >23 GHz 50, 100 GS/s
Typical temperature derating
Frequency TC, (dB/°C)
DC — 5 GHz 0.005 dB/°C
10 GHz 0.010 dB/°C
15 GHz 0.025 dB/°C
20 GHz 0.045 dB/°C
25 GHz 0.065 dB/°C
30 GHz 0.115 dB/°C
33 GHz 0.160 dB/°C
Analog bandwidth ≥4 GHz,
≤20 GHz models
DC 50 Ω coupling, full bandwidth, TCA-292mm or TCA-N adapter, operating ambient temperature
15 °C to 40 °C (59 °F to 104 °F).
Enhanced bandwidth only applies to full scale (FS) settings of 100 mV, 200 mV, 500 mV, 1 V, and
2.5 V. Enhanced bandwidth of 4 GHz, 6 GHz, and 8 GHz is only available at 25 GS/s and 50 GS/s.
Use the Temperature variation table to determine the amount of performance derating above the
temperature limit.
Vertical system analog channels (cont.) Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C
series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 9
