Tektronix DPO70000C/DX Series Technical Reference

DPO7254C, Without enhanced
bandwidth
40 GS/s Analog bandwidth setting
Input Frequency 2.5 GHz 0.5 GHz 0.25 GHz 0.02 GHz
10 MHz 5.9 bits 6.3 bits 6.5 bits 6.6 bits
510 MHz 5.9 bits 6.3 bits
1010 MHz 5.6 bits
1510 MHz 5.6 bits
2010 MHz 5.2 bits
2510 MHz 4.5 bits
20 GS/s Analog bandwidth setting
Input Frequency 2.5 GHz 0.5 GHz 0.25 GHz 0.02 GHz
10 MHz 5.9 bits 6.3 bits 6.5 bits 6.6 bits
510 MHz 5.9 bits 6.3 bits
1010 MHz 5.6 bits
1510 MHz 5.6 bits
2010 MHz 5.2 bits
2510 MHz 4.5 bits
10 GS/s Analog bandwidth setting
Input Frequency 2.5 GHz 0.5 GHz 0.25 GHz 0.02 GHz
10 MHz 5.9 bits 6.3 bits 6.5 bits 6.6 bits
510 MHz 5.9 bits 6.3 bits
1010 MHz 5.6 bits
1510 MHz 5.7 bits
2010 MHz 5.8 bits
2510 MHz 5.5 bits
Vertical system analog channels (cont.) Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C
series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 25

Tektronix DPO70000C/DX Series Specifications

General

Brand	Tektronix
Model	DPO70000C/DX Series
Category	Test Equipment
Language	English
